Description
Interactive LED Double Modules Human Body Infrared Induction Light Module 32 LED lights with Remote control
This is anĀ interactive LED module.TheĀ moduleĀ comes pre-programmed with 8Ā different effects that respond to motion and gradually fade back to idle when there is no motion, making them ideal for interactive LED walls, bar tops, and coffee tables.Each module is controlled by an on-board microcontroller and functions as a self- contained, stand-alone device.The size of module is 8 x 4 inches (20cm x 10cm) , the module has thirty-two 5mm high-gloss LED beads, the spacing between the beads and the lamp beads is approximately 2.5cm, each sensing unit (infrared proximity sensor) controls 4 LED lights at the same time, each module has 8 induction units for all lights
Specifications
-Module size: 8Ā X 4Ā inches (20Ā Ć 10cm) wide
-Circuit board thickness: 1/16″ (1.6 mm) nominal
–Shipping weight: 158g
-LEDs per module: 32
-LED type: Ultrabright,Warm white,5mm OD, with wide viewing-angle diffused lens except as specified
-Sensors per module: 8
-Sensor type: Near-infrared proximity detector (active/passive)
-Sensor range (active): 10 cm (typical), in dark room
-surface types: Can be operated below most clear glasses and plastics, with or without surface frosting.
-Response functions: 8Ā response effects, selectable by button press
-Proximity sensor sensitivity: the closer, the lightĀ is brighter
-Input voltage: 12 V DC, regulated
-Current requirement: 400mA capacity per panel
Module stitching:
Edge-to-edge stitching: Provides edge-to-edge seamless stitching in both horizontal and portrait directions
Maximum splicing size: no restrictions
Take following picture as example
